SquA RGB 120mm PWM PC Case Fan, Triple Pack with RGB Control Box
- Unique square-shaped RGB frame at the front and
- diamond bright at the back
- Support addressable RGB motherboard sync
- Enlarged blade surface increases more airflow by 40%
- Optimized low 300RPM
Color
Overview
Unique Square-shaped Lighting
SquA RGB features square-shaped lighting and also supports addressable RGB lighting sync with 16.8 million color options
Case Moddings and Builds with Square-shaped Lighting Fan
SquA RGB provides users with 2 types of lighting patterns to make the perfect match with system configuration
Diamond Bright Behind SquA RGB
A gleam through the holes around the back of the frame delivers the incredible visual experience as diamonds shining in the dark
Addressable RGB Lighting Synchronization
Synchronizable RGB lighting via addressable RGB header of motherboards (3 pin assignment is 5V/D/G)
Up to 40% Stronger Airflow
The enlarged blade surface can create up to 40% stronger airflow than other RGB fans
SquA RGB
Other
ENERMAX’s Air Inlet Design
ENERMAX’s Air Inlet Design brings more air in and also facilitates the airflow efficiency
Vortex Frame Design
Vortex frame design can generate concentrated airflow, especially perfect for CPU cooler
Optimized low 300RPM starting speed
The smart PWM speed control provides 300RPM starting speed for superior silent experience
Vibration-damping Rubber Pads
Vibration-damping rubber pads absorb the excessive vibration and noise
Fan Package
2 ways to control RGB lighting effects
Through Motherboard Software
Users can sync the RGB lighting with motherboards featuring addressable RGB headers (3 pin assignment is 5V/D/G)
Through ENERMAX Integrated RGB Control Box
Users can use the included control box to adjust preferred lighting effects (10 pre-set effects), brightness and speeds
Product Introduction
Specifications
General Data
- Model
- UCSQARGB12P-BP3
- Fans/Model
- 3
- Dimension (mm)
- 120(W) x 120(H) x 26(D)
- Speed (RPM)
- 300- 1500 (±10%)
- Air Flow (CFM)
- 24.53 ~ 68.27
- Air Flow (m³/h)
- 41.67 ~ 115.99
- Static Pressure (mm-H2O)
- 0.17 ~ 1.898
- Fan Maximum Noise (dBA)
- 12 ~ 23
- Rated Voltage Fan (V)
- 12
- Rated Current Fan (A)
- 0.21
- Rated Voltage RGB LED (V)
- 5
- Rated Current RGB LED (A)
- 0.68 / fan
- MTTF (hours)
- ≧100,000 @ 25°C
- Connector
- 1 x 4-pin PWM connector 1 x 3-pin ARGB connector (5V/D/G)
- Accessory
- 1 x ENERMAX integrated RGB control box 1 x ARGB 3 to 1 cable (5V/D/G) 1 x GIGABYTE ARGB adapter 1 x PWM 3 to 1 cable 1 x Molex adapter 12 x Screw
Shipping Information
- EAN
- 4713157724007
- UPC
- 819315024003
- Box Dimension
- 133 x 160 x 100 mm
- Gross Weight / unit
- 0.74 kg
- Carton Dimension
- 538 x 335 x 309 mm
- Q'ty / carton
- 20 PCS
- Gross Weight / Carton
- 14.8 kg
