MARBLEBRON 850 Watt 80 PLUS Bronze Semi-Modular Power Supply
- 80 PLUS® Bronze certified 850W power supply
- Compact chassis with 140mm chassis in-depth
- 120mm high-pressure fan with SAC (Smart Airflow Control)
- Japanese electrolytic capacitors
- Single rail +12V design & DC to DC circuit
- RGB function with built-in 14 lighting modes
Color
Overview
850 Watt Power Supply, 140mm Chassis In-depth
850 watt output power supports high-end graphic cards
Compact size design, easily install in main stream chassis
80 PLUS® Bronze certified with 88% efficiency @50% load
Reduce unnecessary power consumption and excess heat to conserve energy to reduce carbon footprint and lower electric bill
80 PLUS® Bronze certified ensures lower power and excess heat with up to 88% efficiency @230VAC 50% load
Energy conservation
Meet 2013 Erp Lot 6 of EU Energy Efficiency standard
Energy conservation decreases environment impact
Silence Operation
120mm high-pressure fan
Generates a compressed air stream to rapidly cool down components
SAC (Smart Airflow Control) design
Regulates noise levels to inaudible 14dB(A) at lower loads
Easy Installation
Semi-modular design low-profile black flat cables
- Connect only the cables you need
- Highly flexible and easy to assemble
- Easy to bend and storage inside the case
- Make cable management easier and improve the airflow inside the PSU-shroud design chassis
Longer product lifespan
High-quality Japanese 105°C electrolytic capacitors
Provide long-term durability and reliability to ensure PSU have longer lifespan and avoid buying new one in short-term
User friendly
DC to DC design with 12V single rail
Delivers stable DC output and supports high-end graphic cards and processors
INDUSTRIAL SAFETY STANDARDS
Multiple circuitry protection of OVP, UVP, OPP, SCP and OTP
PSU will shut down immediately in any dangerous situation to prevent the system from breaking down and keeping all the components intact
RGB FUNCTION
- One button to turn on the RGB lighting effects
- Built-in 14 smart lighting modes
- Two ways to light it up by M/B sync and built-in button
Product Introduction
Cables & Connectors
| EMB850EWT-RGB | |
| Mainboard 24 Pin | 1 [ 1x 60cm ] |
| CPU 4+4 Pin | 2 [ 1x 65cm ] [ 1x 60cm ] |
| PCI-E 6+2 Pin (8 Pin) | 4 [ 2x 50/15cm ] |
| 2xSATA + 1x4 Pin Molex | 6 + 3 [ 3x 45/15/15cm ] |
| 2xSATA + 1x4 Pin Molex + 1xFDD | 2 + 1 + 1 [ 1x 45/15/15/15cm ] |
Notice:
For users that are looking to put in high end, power demanding GPU card, please connect 6 / 6+2P PCI-E connector(s) from your ENERMAX power supply to them correctly. This will prevent motherboard overloading and possibly cause damage to your system including your ENERMAX power supply. Once this occurs, it will be treated as improper system configuration and any damage on the power supply as a result of it, will not be covered under ENERMAX manufacturer’s warranty. Please refer to your motherboard & GPU card’s user manual to configure your system properly to prevent motherboard overloading damage to your system and your power supply.
Either sleeved or flat type modular cables in the box are all compatible with your newly purchased power supply. Please only use the modular cables provided in your ENERMAX power supply package. Do NOT use other modular cables to prevent pin configuration damage to your system and your power supply.
Info for DC connector’s rated current: The safety current is 6A per single DC wire. Please be noted that overloading could cause the connector or wire meltdown and could void the warranty.
Specifications
General Data
- 80 PLUS Efficiency
- BRONZE
- Modular
- Semi-modular
- Cable type
- Black flat
- Total power (W)
- 850
- Input Voltage (V)
- 100-240
- Input Current (A)
- 11-5.5
- Input Frequency (Hz)
- 47-63
- Fan size (mm)
- 120
- Operating temperature (°C)
- 40
- MTBF (hours)
- >100K
- Protection
- OVP, UVP, OPP, OTP, SCP
- Dimension (D x W x H), (mm)
- 140 x 150 x 86
Output
- +3.3V(A)
- 20
- +5V(A)
- 20
- +12V1(A)
- 70
- -12V(A)
- 0.3
- +5Vsb(A)
- 2.5
- Combined Wattage 12V (W)
- 840
- Combined Wattage 3.3V + 5V(W)
- 130
Shipping Information
- EAN code
- 4713157726087
- UPC code
- 819315026083
- Box dimensions (D x W x H), (mm)
- 248 x 211 x 95
- Gross Weight / unit (kg)
- 2.28
